Digital audio inputs   ES-LINK 2 Input signal formats Linear PCM (ES-LINK5 format) 44.1k to 768kHz 48bit DSD (ES-LINK5 format) 2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz XLR 1 Input level 5.0Vp-p Input impedance 110 Input signal formats (DUAL connection) Linear PCM (DUAL AES format) 88.2k to 384kHz, 16bit to 24bit Linear PCM (ES-LINK3 format) 88.2k to 192kHz, 48bit DSD (ES-LINK1, ES-LINK2, DoP format) 2.8MHz Input signal formats (SINGLE connection) Linear PCM (AES/EBU format) 32k to 192kHz, 16bit to 24bit DSD (ES-LINK1, ES-LINK2, DoP format) 2.8MHz RCA 2 Input level 0.5Vp-p Input impedance 75 Input signal formats Linear PCM (IEC60958 format) 32k to 192kHz, 16bit to 24bit DSD (DoP format) 2.8MHzt OPTICAL 1 Input level –24.0 to –14.5dBm peak Input signal formats Linear PCM (IEC60958 format) 32k to 192kHz, 16bit to 24bit DSD (DoP format) 2.8MHzt USB 1 (USB2.0 standatd) Input signal formats Linear PCM 44.1k to768kHz, 16bit to 32bit DSD 2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz Analog audio outputs   XLR/ESL-A x 1 (mono) each for left and right channels Output impedance 100 Maximum outout level 5.0Vrms (1kHz, full scale PCM signal input, 10k loaded) RCA x 1 (mono) each for left and right channels Output impedance 47 Maximum output level 2.5Vrms (1kHz, full scale PCM signal input 10k loaded) Clock input   BNC x 1 each for left and right channels Input impedance 50 Input level Sine wave 0.5 to 1.0Vrms Frequency that can be input 10MHz (±10ppm) General   Power supply     AC 220 to 240V. 50/60Hz   AC 120V. 60Hz   AC 220V. 60Hz   AC 230V. 50Hz Power consumption 20W External dimensions(W×H×D) 445 × 132 × 448mm 17-⅝" × 5-¼" × 17-¾" (including protrusions) Weight   Left channel 23.1kg / 51 lb Right channel 23.0kg / 50-¾ lb Included accessories Power cord × 2 HDMI cables × 2 Felt pads × 8 Owner's manual × 1 Warranty card × 1   ]]>
